Balaji Electro Controls aims to reign in standards in the electrical control panel industry by adopting best practices and creating awareness to clients, and professionals in the domain to ultimately achieve the goals of safety and efficiency, and being at par with international standards.

Most often, it’s a choice one makes concerning a product based on their budget. However, when it comes to electrical control panels, one doesn’t have a choice, as there cannot be any compromises concerning safety, power efficiency, and quality.

As the world is evolving, every industry is also evolving and the standards are changing to enhance the overall safety and efficiency of power transmission, usage, and quality of power.

Balaji Electro Controls have products are IEC 61439 compliant.

It is important to note that more than two-thirds of the countries across the globe have implemented IEC standards. So while choosing a control panel manufacturer, it is critical to check and verify the authenticity of the manufacturer, if they have applied IEC standards, including designing and building of panels.

TYPE TESTED ASSEMBLIES (TTAs)

A low voltage switchgear and control gear assembly conforming to an established type or system without deviations likely to significantly influence the performance, from the typical assembly verified to be under this standard.

When type tested assemblies are being used it is important to check that they are constructed under the type test and that any deviations from the type tested construction do not have a significant influence on the performance as verified by the type test.

Deviations from the type test, which could affect the performance, are:

• Structural changes will affect the mechanical strength of the assembly.
• Incorrect sizing of busbar or cross-section area which will affect the temperature-rise limits.
• Busbar supports spacing, changes in the type or quantity of busbar supports, and the busbar support structure. Which will affect the short circuit withstand strength.
• Reduction in compartment size may result in overheating of components and wiring may cause a component breakdown or insulation failure and possible short circuit faults.

PARTIALLY TYPE TESTED ASSEMBLIES (PTTAs)

A low voltage switchgear and control gear assembly, containing both type-tested and non-type tested arrangements, provided that the latter are derived (e.g. By calculation) from type-tested arrangements which have complied with the relevant tests.

The type-tested arrangements should cover as a minimum the mechanical assembly, the main and distributor busbar systems complete with all busbar supports.

The standard allows for use of the other parts in the assembly that are not part of the type test for the assembly, for example, components and compartment layouts provided they have been derived (e.g. By calculation) from type tested arrangements.
